Digital Temperature Gauge ACT-118
Details
|
Main Features |
Large screen LCD with high resolution and no collimation error. | |||
| Peak value record function. | ||||
| Temperature percentage dynamic demonstration | ||||
| 1~15min auto power-off. | ||||
| Micro-power consumption supports 2000 hours constant working time in power-saving mode. | ||||
| Parameters correcting, null point and error could be amended on the broad. | ||||
| Sample rate: 1 time/s. | ||||
| Backlight make it could be seen in the dark environment. | ||||
| 5 units: ℃, ℉, K, Ra, Re | ||||
| Main Parameters | Measuring Range | -200℃~500℃ | Accuracy | 0.2%F.S, 0.5%F.S |
| Stability | ≤0.1%F.S /year | Battery | 3.6V DC | |
| Display Mode | 5 Digits LCD | Display Range | -19999~99999 | |
| Environmental Temperature | -20℃~70℃ | Relative Humidity | 0~90% | |
| Temperature Sensor | PT100 | Connector Material | Stainless Steel | |
Overall dimensions(Unit:mm)
Selection Guide
|
Selection Guide of ACT-118 Digital Temperature Gauge |
|||||
| ACT-118 |
|
||||
| InstallationMode | J | Radial | |||
| Z | Axial | ||||
| Thread Connection | G12 | G1/2 | |||
| M20 | M20*1.5 | ||||
| M27 | M27*2 | ||||
| Measuring Range | According to customer’s request | ||||
| Insert Depth | L...mm | ||||
Our Advantages
1. Specializing in the field of measurement for 16 years
2. Cooperated with a number of top 500 energy companies
3. About ANCN:
*R&D and production building under construction
*Production system area of 4000 square meters
*Marketing system area of 600 square meters
*R&D system area of 2000 square meters
4. TOP10 pressure sensor brands in China
5. 3A credit enterprise Honesty and Reliability
6. National "Specialized in special new" little giant
7. Annual sales reach 300,000 units Products sold worldwide
Factory
Our Certification
Explosion Proof Certificate
Certificate of Patent
Customization Support
If the product shape and performance parameters have special requirements, the company provides customization.
Product Advantages Introduction
At the heart of the ACT-118 digital thermometer is the state-of-the-art PT100 sensor. Known for their exceptional accuracy and reliability, the PT100 sensor ensures precise temperature measurement even in the most demanding environments. Whether you are monitoring the temperature of water, oil, chemicals or machinery, this innovative sensor always guarantees the highest accuracy.
The ACT-118 Digital Thermometer's LCD display adds extra convenience and efficiency to your temperature monitoring tasks. The clear readability of the display provides a seamless user experience, allowing you to easily read and interpret temperature measurements. The thermometer has a user-friendly interface that simplifies operation and ensures easy navigation of various parameters.
With compatibility in mind, the ACT-118 digital thermometer is designed to be compatible with stainless steel. This allows for seamless integration into existing equipment and systems in industries that rely heavily on stainless steel components. Strong compatibility not only ensures hassle-free installation, but also guarantees long-lasting performance and durability.
The versatility of the ACT-118 digital thermometer makes it the first choice for many industries. Water systems can benefit greatly from their ability to accurately monitor temperature fluctuations to ensure optimal performance and safeguard the integrity of the water supply. In petroleum and chemical engineering, instrumentation becomes an indispensable tool for maintaining precise temperature levels, thereby optimizing processes and ensuring compliance with safety regulations. In machinery applications, the ACT-118 ensures efficient operation of critical components by providing real-time temperature data, allowing timely intervention when necessary.
